Junkers Ju 188 |
Junkers Ju 188 |
| The Ju 188 E with enlarged wings and straight tail unit, improved canopy
and more powerful engines was a direct development of the Ju 88 E and was
in use from Sommer 1942 in the night bomber units of the Luftwaffe. With
it's imporved bombload of 3.000 kg and improved armament this version was
a very effective bomber and deadly enemy. The versions D,F and H were for
reconnaissance purposes and in the year 1944 the versions A, E, G, and S
were spread over the Luftwaffe as bombers. The version G was able to load 3.300 kg bombs and the not armed S with a special injection reached a maximum speed of 686 km/h, comparable with the fastest version of a Mosquito.
|
| Series: A,C,D,E,F,G,H,S,V | ||||||
| e.g.type: | Use: | |||||
| Ju 188 F-1 | Reconnaissance plane | |||||
| Ju 188 A-2 | Bomber | |||||
Data of the: Ju 188 A-2 |
||||||
| Length: | 14,95 m | |||||
| Width: | 22,02 m | |||||
| Height: | 4,45 m | |||||
| Crew: | 4 | |||||
| Motor: | Jumo 213 A | |||||
| Power: | 2 x 1775 PS | |||||
| Vmax: | 520 km/h | |||||
| Range: | 2400 km | |||||
| Ceiling: | 9500 m | |||||
| Armament: | 1 x MG151/20 | |||||
| 1 x MG151 | ||||||
| 1 x MG121 | ||||||
| up to 3.000 kg bombload | ||||||
.
|
||||||
|
||||||
